Gulf Center provides advanced recycling solutions for the concrete production industry, in partnership with BIBCO© Germany — a global leader in concrete recycling technology.

Our Wet Concrete Recycling Systems are designed for ready-mix and precast plants, offering efficient recovery of returned concrete, process water, and aggregates.

From ready-mix reclaimers and grey-water treatment to filter presses, settling pits, and truck rinsing systems, Gulf Center delivers complete recycling setups that help clients reduce waste, save water, and meet environmental sustainability standards.

Efficient wet concrete recycling systems engineered to recover aggregates, sand, and process water — delivering sustainable, zero-waste solutions for ready-mix and precast plants.

Gulf Center provides two advanced systems for managing leftover ready-mix concrete and promoting sustainable production within concrete batching plants:

1. Reclaiming Systems (Open-Loop)

These systems allow aggregates and sand contained in returned ready-mix to be separated, cleaned, and reused in the batching process.
Process water is directed to settling pits, where it can also be reused.
The fine materials collected at the bottom are manually removed and disposed, making it an open-loop recycling approach.

2. Recycling Systems (Closed-Loop)

A complete closed-loop solution that integrates a reclaimer with a water treatment unit, enabling full reuse of aggregates, sand, and grey-water.
This results in zero discharge, eliminating the need for waste disposal and minimizing environmental impact.
All systems are engineered in partnership with BIBCO Germany
and designed for ready-mix and precast concrete plants operating in Kuwait and the GCC.

COMTEC & COMTEC Mobile Version Compact, high-performance recycling units available in both stationary and mobile configurations for maximum flexibility on-site

Pump Discharge Conveyor (PDC) Integrated conveyor system for efficient discharge and transfer of recycled aggregates and slurry.

CONREC, RWS & RWS Mobile Systems Advanced concrete reclaimer systems for separating sand, gravel, and process water — with mobile options for rapid deployment.

External Bucket Row Designed for easy handling and maintenance, ensuring smooth material flow and reduced downtime.

BOUBLEX Dual-stage recycling unit combining washing and separation for superior recovery and water treatment efficiency.

Special Tailored Solutions Custom-engineered systems built to meet specific site, capacity, and environmental requirements across Kuwait and the GCC.

Wet Concrete
COMTEC & COMTEC Mobile Version
Parameter	Specification
Concrete Wash-Out Capacity	4, 10, 20, and 30 m³/h
Shock-Discharge	Available
Water Volume	3 – 6 m³ (improves capacity & washing quality)
Separation Cut	0.2 mm
Bearing Design	Positioned outside water zone
Hopper Size	Variable, up to 3.5 m
Footprint	Compact
Heating System	Optional, heatable version
Machine Hood	Aluminium, hinged, gas-spring assisted
Surface Protection	Fully hot-dip galvanized
Installation	Mobile version mounted on skid with all components pre-installed; only requires electrical and water connections on site

Wet Concrete
CONREC
Parameter	Specification
Washing Capacity	18 or 28 m³/h
Separation Cut	0.2 mm
Bearings	Positioned outside water area
Hopper Size	Up to 3.5 m
Footprint	Compact
Heating System	Optional
Dosing Buffer	External buffer for emptying up to 10 trucks simultaneously
Coating	Fully hot-dip galvanized

Wet Concrete
RWS & RWS Mobile
Parameter	Specification
Washing Capacity	12 m³/h
Separation Cut	0.2 mm
Bearings	Positioned outside water area
Heating System	Available
Galvanization	Fully hot-dip galvanized
Height Adjustment	Adjustable screw height to compensate for wear and extend service life
Installation	Mobile skid-mounted version with preinstalled components; requires only water/electrical connection and piping setup on site

Wet Concrete
Doublex
Parameter	Specification
Function	Processes two materials in one recycling system
Material Separation	Complete, independent processing and water loop
Feeding System	Separate hoppers, wash chambers, and overflows
Drive System	Single drive and unified control panel
Footprint	Reduced vs. two standalone systems
Energy Efficiency	Lower power consumption due to one drive
Capacity (Mortar/Anhydrite)	4, 8, or 12 m³/h
Capacity (Residual Concrete)	6, 10, or 20 m³/h
